by boelle

This is the same as by @farscape1

I just collected the bits into Fusion360 so that each part can be shown or hidden.

It will come very handy during assembly.

Only part that I changed was the Mid part. The org. would not fit a Prusa printer, so all I did was joining them to one part and split it half way.

Fusion360 Public download link: https://a360.co/2ScMzRf

I will also do a slideshow video of my assembly when i get that far

STATUS: Printing parts

Materials needed - will update once all parts are printed:

Red ........? kg
White........ ? kg
Black ........? kg
Gray .......? kg
Green.......? kg
Blue .... ? kg
Loctite Super Glue - Precision (2062278)
It's a small 5g bottle and it's thin as water. A little goes a long way and it hardens very fast

Print Settings

Printer Brand:

Prusa

Printer:

i3 MK2.5

Rafts:

No

Supports:

Yes

Resolution:

0,2

Infill:

25%

Filament:                                            Devil Design PLA

Notes:

Standard slicer setting except:

3 perimeter
Infill 25%

Where Support material is needed set XY seperation to 100%

I also changed retract speed to 60 mm/s and disabled retract on layer change

Filament settings was set to standard Prusament and worked fine with Devil Design PLA
