by spofff
As my resolution for this year was to be closer to nature and more environmentally healthy I thought it would be perfect to design, print and use this bird feeder.
I would love it if you where to print this yourself (and so would birds)
Notes for assembly:
Everything will slot together and you should put the pin through one of the slide bars, through the tube, through the bottom piece and then finally out the other end through the second slid bar.
I would recommend using some simple glue or double sided tape to make sure the slide bars stay in place.
After that all you have to do is slide a piece of string through the top hole of the tube, then through the holes on the lid, then back through to the other top hole in the tube with both ends of the string having a knot to keep it in place.
Rafts:
Yes
Supports:
Yes
Resolution:
0.2
Infill:
20% (Except for tube, solid)
Notes:
The tube should be printed with 3 walls as to make it solid.
