Print Settings
Printer brand:
Prusa
Printer:
i3 MK3
Rafts:
Doesn't Matter
Supports:
Yes
Resolution:
.15
Infill:
20%
Filament_brand:
Any
Filament_color:
Any
Filament_material:
PLA
Post-Printing
You will need to print the following: 1 Main Body 2 Side Pieces 1 Top Disk 8 Pegs 1 Rod Cap 1 Handle Washer 11 Handle Rings 1 Pommel 8 Ornate Panels 1 Top Rod 1 Middle Rod 1 Bottom Rod 1 Spacer (optional) 1) To put these pieces together, attached the side pieces of the hammer to the main body using the pegs. There are four alignment holes on each side of the main body that line up to four alignment holes on each of the side pieces. LEAVE ONE SIDE OPEN UNTIL YOU HAVE FINISHED THE NEXT STEP. 2) Put together the 3 pieces of the rod and slide it up into the hammer head. Take the Rod Cap and glue it to the top of the rod and the bottom side of the main body. This cap is designed to hold the rod more securely inside the hammer. 3) Place the next side of the hammer head onto the main body and glue it up 4) Glue in each of the ornate panels into the recessed areas on the sides of the hammer. It should be a very close fit so they align properly. 5) Slide the handle washer up the rod to the main body and glue it up 6) Using the spacer, slide each of the handle rings up the rod and glue them into place. If you wrap the rod in some sort of fabric or leather, remember to increase the diameter of the rings and handle washer to accept the new diameter. The rings currently only fit over a 29mm rod. 7) Once all of the rings are glued on, place the pommel on the bottom and glue it up. The pommel has a hole that accepts the 29mm rod so make sure you don't wrap the rod all the way down, only wrap where it is visible. And you are done! Enjoy Mjolnir!
